Basic parameters

• Length (mm)

  17,970

• Width (mm)

  2,500

• Height (mm)

  3,320

• Wheelbase (mm)

  5,900/5,900

• Tire

  295/80R22.5

• Maximum speed

  90

• Maximum number of seats

  47+7

• Maximum manufacturer's total mass (kg)

  26,000

• Front/middle/rear axle (kg)

  6,000/10,000/10,000

• Floor type

  Low entry

New energy power system

• Traction battery (kWh)

  528.13

• Rated/peak power (kW)

  150*2/260*2

• Maximum gradeability

  18%(20km/h,65s)

• Dual-plug

  ●

• Pantograph charging

  ○

• Charging plug current (250A)

  ●

• Charging plug current (500A)

  ○

• Emergency Assist for Pedal Misapplication(EAPM)

  ●

• Intelligent power control

  ●

Seat

• Wheelchair area

  ●

• ISRI driver seat

  ●

Interior

• Driver partition

  ●

• Wheelchair ramp

  ●

Exterior

• Passenger door

  ● 2-2-0
  ○ 2-2-2

• Single-layer side window glass

  ●

• Manual driver window

  ●

• Standard front windshield glass

  ●

A/C

• Heating and cooling

  ●

• Heating/cooling defroster

  ●

Chassis

• Front axle

  ZF RL82A

• Drive axle

  ZF AV133

• Third axle

  ZF AV133

• Suspension system

  Air suspension, hydraulic dual-way shock absorbers; lift system (with kneeling)

• ECAS

  ●

• Steering wheel position

  RHD

• EPB

  ●

Safety and driving assistance system

• Forward Collision Warning (FCW)

  ●

• Lane Departure Warning System(LDWS)

  ●

• Moving Off Information System (MOIS)

  ●

• Blind Spot Information System (BSIS)

  ●

• Intelligent Speed Assistance (ISA)

  ●

• Driver Drowsiness and Attention Warning (DDAW)

  ●

• Advanced Driver Distraction Warning (ADDW)

  ●

• Electronic Braking System (EBS)

  ●

• 360° panoramic view system

  ●

• Electronic rearview mirror

  ●

• Reversing radar

  ●

• Intelligent headlamp

  ●

Audio-visual entertainment and lighting

• Adjustable instrument

  ●

• Microphone

  ●

• Headlamp, LED

  ●
